Diamondback Atroz 2
Details
We love hardtails, but there's no denying the benefits of full-suspension mountain bikes — the added comfort and control. Unfortunately, dualies often add another thing: more dollar signs to the price tag. That's not the case here. The Atroz utilizes sealed cartridge bearings in an understated single-pivot design to deliver smooth, durable performance. The Atroz 2 ups the ante with Shimano hydraulic disc brakes, Suntour air-sprung rear suspension and an easy-to-operate single-ring drivetrain—features you usually find on bikes with a whole lot more dollar signs on their price tags.
- Hand-built 4-inch travel aluminum alloy, full-suspension frame is super strong
- Optimized single pivot with sealed cartridge bearings for smooth, durable performance
- Shimano reliability in their wallet-friendly Acera M3000 9-speed drivetrain
- Shimano MT200 hydraulic disc brakes w/ 180mm rotors front and rear
- 27.5" wheels offer quick handling
Specs
| Frame | Atroz 6061 T-6 Aluminum 27.5 Trail w/ 4" travel, Optimized Single Pivot, Tapered Steerer, Machine Formed Top Tube, Butted/Formed Down Tube, Sealed Cartridge Bearing Pivot, Seat Tube Routed for Internal Dropper Post, Aggressive Geometry, Replaceable Hang |
|---|---|
| Fork | SR Suntour XCM 120mm Travel, 30mm Stanchions, w/Preload Adjust |
| Headset | FSA NO.57, Sealed Cartridge for Tapered Headtube |
| Rear Shock | SR Suntour Raidon-R, Air Shock w/ Rebound Adjust, 184x44mm |
| Rims/Wheels | 32H, DDM-5, 27.5 Double Wall |
| Hubs |
Front: Formula Hubs, 32h Alloy w/ CNC Disc Mount Rear: Formula Hubs, 32h Alloy Cassette w/ CNC Disc mount |
| Spokes | 14g Stainless Steel |
| Tires | VEE Rubber, Flow Snap, 27.5x2.35" |
| Crankset | Alloy Arm |
| Chainrings | 30T Steel "Narrow Wide" Single Ring |
| Bottom Bracket | Sealed Cartridge |
| Chain | KMC Z99, 9 Speed |
| Front Derailleur | Full ISCG-05 Chain Guide w/ Roller |
| Rear Derailleur | Shimano Acera M3000 Shadow, 9 Speed |
| Cassette/Rear Cogs | Shimano HG200, 9 Speed, 11-36T |
| Shifters | Shimano Acera M3000, 9 Speed |
| Handlebars | Diamondback, 750mm Wide, 15mm Rise, 31.8 Bar Bore |
| Tape/Grips | New DB "Flanged" 135mm Silcone |
| Stem | Diamondback "Shortie", 45mm Reach, 31.8 Bar Bore |
| Brake Levers | Shimano MT200 Hydraulic |
| Brakes | Shimano MT200 Hydraulic Disc, w/180mm Front and Rear Rotors |
| Pedals | DB4L Alloy Platform |
| Saddle | DB Sync'r Saddle |
| Seat Post | Alloy Micro Adjust, 30.9mm |
| Accessories & Extras | Tool Kit |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Satin Blue / Large | 791964573753 | 02-0210652 | 21520 |
